Introduction: |
BXM-FXJ7 solar cell tester and sorter with class AAA light source,double probes
touch between up and down, power controlled by a microcomputer,LCD screen
display, Pulse xenon lamp flash pulse width can be adjusted, double flash
for testing Rsh and Rs, and the combination of the combination of the file. |
Benefits: |
1.Use Ceramic reflector cavity; |
2.Use pure quartz filter; |
3.Graph display: I-V curve, Pm curve, I curve, V curve, and standard cells I curve; |
4.Test Parameters: Voc, Isc, Ipm, Vpm, Pmax, FF, Eff, Rs, Iwork, light intensity; |
5.Compensation and amendment: Testing system light intensity can automate
compensation and the temperature can automate amendment; |
6.Measurement results are immediately shown on the PC screen, and can be printed
from a printer at once or data preserves, diversion and database settle. |
Specification: |
SPECTRUM: |
AM1.5G filter, IEC60904-9 During 400nm-1100nm
CLASS A |
Light source: |
long-arc pulsed Xenon lamp, lifetime≥300,000 times |
Light intensity: |
20mw/cm²-120mw/cm², automatic compensation. |
Test mode: |
Test and classify 10 classes and save to the special
document automatically. |
Radiation instability: |
STI ≤± 0.5% LTI ≤± 1% CLASS A |
Radiation non-uniformity: |
≤±2% CLASS A |
Peak Width: |
20ms |
Data collect point: |
8000,Temperature emendation ,0℃-80℃ automatic |
Testing range: |
Voltage 5V(max), Current10A(max) |
Working time: |
≤3 second per piece |
Testing data uniformity: |
≤±1.0% |
Max testing area: |
200×200mm |
Dimensions: |
900×800×1950mm |
Weight: |
100Kg |
Power supply: |
220VAC, 10A, 50 Hz, 2Kw, single phase 3 wires |
CONFIGURATION: With the machine, there is 1 computer, 1 set of software, 1 Xenon lamp in the machine
and 1 Electric load. |
